5-4 Module Configuration Using an ASCII Terminal
Top Level Setup Menu The Top Level Setup Menu provides six selections.
Top Level Setup Menu
• To redisplay the above menu, press [ENTER]
.
• To access the corresponding menus (described on the following
pages), press [1] through [5].
• To save changes and exit, press [X]. This enables the DH-485
and DF1 ports.
Change Parameters for Menus 1 through 4
To change any of the parameters in menus 1 through 4:
1. Select the parameter you wish to change. The current parameter
setting and a prompt for entering a new value appear at the
bottom of the screen.
2. Type in the new value and press [ENTER].
If you enter an invalid value, the ASCII terminal beeps and the
prompt remains. Refer to the tables on pages 5-5 through 5-12
for the valid parameter options.
IMPORTANT
After configuration is complete, place the module in
Run mode as described on page 4-15.
If you operate the module in Configuration mode,
cycling power will disable the DF1 and DH-485
ports, return to the configuration mode, and display
the Top Level Setup Menu on your ASCII terminal.
1. CONFIG PORT
2. DF1 PORT
3. DH 485 PORT
4. DF1 PROTOCOL
5. DISPLA Y PARAMETERS
X. SAVE AND EXIT
Enter Selection. . . . .
1747 KE Module, FRN #
Top Level Setup Menu.
