Locate the circled number
in the MCC bit/word map
Interpreting Diagnostic Information
In LEDs and Error Codes
Chapter 5
5-6
9000 Series Error Codes for the MCC (Returned in SYS)
When you attempt to download the MCC to the SPI module, it returns
SYS with an error code each time it detects a data entry error.
We list 9000 series error codes (Table 5.B) and the corresponding MCC
bit/word map to show the data fields where your entered data was detected
as invalid. Locate the circled number in the MCC bit/word map
corresponding to the 9000 series error code.
Table 5.B
9000 Series Error Codes for the MCC (Returned in SYS)
Error Code: Your entry in the MCC was invalid because you entered: In this Entry Field: In MCC at:
9000 a page number greater than 9 Page Number
9001 a page number greater than your total page number entry
g
9002 an AĆF hex character, but the format (MCC word 1, bit 8) specified decimal Device Address
9003 a device address less than 32 for the data format selected in word 1, bit 8
9004 a device ID less than 32 for the data format selected in word 1, bit 8 Device ID
9005 more than one device ID for the same device address (can have only one) (duplicate address)
9006 an ID for a device not supported by the SPI module Device ID
9007 a page number, programmed or downloaded out of sequence Page Number
9008 a total page number greater than 9 Total Pages
9009 a communication rate that does not match allowed selections Baud Select
900A a device ID that does not match device IDs stored in custom configuration Device ID
900B a zone address less then 31 for the data format selected in word 1, bit 8 Zone Address
MCC Bit/Word Map
Word 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
1 CNE Baud Select CNS NF DF MCC Block ID
2 0 0 Page Number Total Pages
3 and 4 0 0 0 0
Error codes may refer to any of the following word pairs (5&6, 7&8, etc.) which define SPI network devices, listed in BTR queue order.
n DS CS PM Reserved Device ID (for first queued BTR)
n+1 Zone Address (for temperature control devices, only) Device Address
