Defining Command and Status Blocks

Chapter 3

3-7

Table 3.F

Word/Bit Definitions of the Custom Configuration Block (CCB)

Word

Number

Bit

Number

Title

Range

Notes

0-7

Device ID

00100000 to 11111110

Use the SPIĆspecified device ID.

1

8-10

Determine

Configuration

DC

(IDĆspecific)

100 = Store configuration

>

101 = Read configuration

>

110 = Overwrite configuration >

111 = Clear configuration

>

If device ID matches a stored ID, SPI returns an error.

If SPI finds no matching ID, it returns an error.

If SPI finds matching ID, new config overrides old.

SPI returns a flag, and ignores all other data in CCB.

11

Clear All

CA

0 = No action

1 = Clear all configurations

The SPI module clears all stored configurations.

12-15

Not used

2

0-7

Number of

BitĆcommand

Words

0 to 60 decimal data

Tells the SPI module how many words containing bit

commands to expect in the CDB.

2

8-15

Number of

Numeric

Setpoints

0 to 30 decimal data

Tells the SPI module how many setpoints and/or

alarm limits to expect in the CDB.

3

0-7

Number of ASCII

Strings

0 to 30 decimal data

Tells the SPI module how many ASCII strings to

expect in the CDB.

3

8-15

Number of

BitĆstatus Words 0 to 30 decimal data

Tells the SPI module how many words containing

status bits to return to the processor in the CDS.

4

0-7

Number of

NumericĆstatus

Words

0 to 30 decimal data

Tells the SPI module how many numeric status words

such as temperature or flow to return in the CDS.

4

8-15

Number of

ASCIIĆstatus

Strings

0 to 30 decimal data

Tells the SPI module how many ASCII strings such as

SPI Revision to return to the processor in the CDS.

Starting

at

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

bit command word sent to the SPI module

at

word 5

0-7

CMD2

starts at 00100010 22

bitĆcommand word sent to the SPI module.

For example: 20 49 for Mode, Machine

Note 1

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

numeric setpoint sent to the SPI module

Note 1

0-7

CMD2

starts at 00100010 22

numeric setpoint sent to the SPI module.

For example: 20 31 for Temperature Setpoint

Note 1

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

ASCII string sent to the SPI module

Note 1

0-7

CMD2

starts at 00100010 22

ASCII string sent to the SPI module.

For example, 20 22 for SPI Revision

Note 1

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

bit status word sent to the processor

Note 1

0-7

CMD2

starts at 00100010 22

bitĆstatus word sent to the processor.

For example, 20 44 for Status, Machine

Note 1

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

numeric status word returned to the processors

Note 1

0-7

CMD2

starts at 00100010 22

numeric status word returned to the processors.

For example, 20 72 for Process Temperature

Note 1

8-15

CMD1

starts at 00100000 20

SPI code pair for the specified

ASCII status word returned to the processor

Note 1

0-7

CMD2

starts at 00100010 22

ASCII status word returned to the processor.

For example, ?? ??

Note 1:

Load commandĆcode pairs in the order given. Leave no blank words. If not using a specified type of command code, the SPI module

expects the next type instead. Command codes for status specify the type of status that you want returned in the CDS.
