Creating Command and Status Blocks
Chapter 4
4-5
Blank CCB Worksheet for Your Application
Write your own entries in this blank worksheet to suit your application.
Important: Because we cannot predict the number of bit, numeric, or ASCII
entries in your application, we give you a blank word column and extra rows
for each type of entry. Enter the number of the file word for each entry, and
use blank rows as needed. Enter device ID and data in the formats that you
specified in MCC word 1 bits 8-10. See notes [1] and [2] below.
CCB Worksheet
Word Write your entries in this column.
1 device ID: name ___________________________________ code ____________
2 # numeric preset words = _____ # bitĆcommand words = ______
3 # bit status words = _______ # ASCII strings = ______
4 # ASCII status words = _______ # numeric status words = ______
Word Write your entries in this column. [1] CMD1 CMD2
5 bit command 1
numeric preset 1
ASCII strings 1
Word Write your entries in this column. [1] [2] CMD2 CMD1
bit status word 1
numeric status word 1
ASCII status word 1
[1] Leave no blank words between groups of entries. If not using a group, put the next group in its space.
[2] Status words that you specify here are returned in CDS whenever the SPI module polls its devices.
