Rockwell Automation Publication 1756-UM005B-EN-P - January 2013 23
Chapter
3
Module Features
Input Compatibility ControlLogix high-speed analog I/O module inputs convert the following
analog signals into digital values:
• Volts
• Milliamps
The digital value that represents the magnitude of the analog signal is then
transmitted on the backplane to an owner-controller or other control entities.
Output Compatibility ControlLogix high-speed analog I/O module outputs convert a digital value
delivered to the module via the backplane into an analog signal:
• -10.5…10.5V
or
• 0…21 mA
The digital value represents the magnitude of the desired analog signal. The
module converts the digital value into an analog signal and provides this signal on
the module's screw terminals.
Topic Page
Input Compatibility 23
Output Compatibility 23
General Module Features 24
Electronic Keying 25
Understand Module Resolution, Scaling and Data Format 35
Features Specific to Module Inputs 37
Features Specific to Module Outputs 46
Fault and Status Reporting 49
