Rockwell Automation Publication 1756-UM005B-EN-P - January 2013 13
What is the ControlLogix High-speed Analog I/O Module? Chapter 1
Table 1 lists the physical features on the ControlLogix high-speed analog I/O
module.
Table 1 - ControlLogix High-speed Analog I/O Module Physical Features
Feature Description
ControlLogix backplane connector Provides an interface to the ControlLogix system by connecting the module to
the backplane.
Connector pins Input/output, power, and grounding connections are made to the module
through these pins with the use of an RTB.
Locking tab Anchors the RTB on the module to maintain wiring connections.
Slots for keying Slots mechanically key the RTB to prevent you from making the wrong wire
connections to your module.
Status indicators Display the status of communication, module health, and calibration
information. Use these indicators to help in troubleshooting.
Top and bottom guides Provide assistance in seating the RTB onto the module.
