Page 111: Appendix

Rockwell Automation Publication 1756-UM005B-EN-P - January 2013
111
Appendix
B
Tag Definitions
When you write configuration for a high-speed analog I/O module, you create
tags in the tag editor. Each configurable feature on your module has a distinct tag
in the controller’s ladder logic.
The following figures show the difference between latching process alarms
through the Module Properties dialog box or the tag editor. Both methods
perform the same function on the module.
Figure 14 - Module Properties
Topic
Page
Data Tag Names and Definitions
Download New Configuration Data
IMPORTANT
Although this appendix describes the option of changing a module’s
configuration through the tag editor, we suggest that you use the Module
Properties dialog box to update and download configuration changes when
possible.
Use this pull-down menu to choose
an input range for channel 0.
