54 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Chapter 3 Common Module Features
Multiple Input Point Densities
ControlLogix input modules use either 8-, 16-, or 32-point densities for greater
flexibility in your application. A point is the termination where a wire attaches to
the input module from a field device. The module receives information from the
device to this designated point, thus signaling when activity occurs.
Common Features
Specific to Output Modules The table below lists features specific to ControlLogix digital output modules.
IMPORTANT Some features are not available on all output modules. The table indicates
which modules support each feature.
Topic Page Available Modules
Configurable Point-level Output States 55 All modules
Output Data Echo 56 All modules
Isolated and Nonisolated Varieties of Output Modules 56 All modules
Multiple Output Point Densities 57 All modules
Electronic Fusing 57 1756-OA8D
1756-OA8E
1756-OB16D
1756-OB16E
1756-OB8EI
1756-OB16IEF
1756-OB16IEFS
1756-OV16E
1756-OV32E
Field Power Loss Detection 60 1756-OA8E
Diagnostic Latch of Information 61 1756-OA8E
1756-OB16IEF
1756-OB16IEFS
Time-scheduled Output Control 63 1756-OB16IS
1756-OB16IEFS
