7 - configure controllogix digital i/o modules, Chapter 7, Configure controllogix digital i/o modules – Rockwell Automation 1756-XXXX ControlLogix Digital I/O Modules User Manual
Page 127: Chapter
Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
127
Chapter
7
Configure ControlLogix Digital I/O Modules
You must configure your module upon installation. The module will not work
until it has been configured. In most cases, you will use RSLogix 5000 software to
complete the configuration. The software uses default configurations, such as
RPI and filter times, to get your I/O module to communicate with its owner-
controller. You can edit the default configuration as needed from the Module
Properties dialog box.
Topic
Page
