5–8 Configuring the Loops
Publication 1771Ć6.4.5 - January 1997
Viewing configuration data
If you want to view the configuration data for a different loop, you
can select
Next or Previous from the Loop menu to cycle through the
loops. You can also press
CTRL + N or CTRL + P.
Enter loop configuration values within the stated ranges. In each
case where a decimal point is shown, if you want to enter a digit to
the right of the decimal point, you must type in the decimal point; the
decimal point is not inferred.
Listing acceptable values
When you position the mouse pointer over a field that requires a
numeric entry (e.g. Run Set point), there will be a brief delay, after
which a small window appears that identifies the acceptable range of
values for that parameter. You can find additional information in the
online help.
The following table provides you with the appropriate values to enter
for each field.
"
Entering Loop
Configuration Values
"
