76
Rockwell Automation Publication 1420-UM001D-EN-P - September 2013
Appendix C
PowerMonitor 500 EtherNet/IP Device Profile
Instance 1 Attribute Values
Product Code Values
Assembly Object Class Code: 04 hex
The assembly object collects attributes from multiple objects, allowing data to or
from each object to be sent or received over a single connection. Assembly objects
are used to produce and/or consume data to/from the network. An instance of
the assembly object can both produce and consume data from the network.
Static assemblies are factory determined and cannot be modified by the user of
the product. Members cannot be added or deleted. The implementation of the
Assembly object shall be static. See Section 5-5 of the CIP Common
Specification for full details of this object.
Attr ID Name Value
0x01 Vendor ID 1 (Rockwell Automation)
0x02 Device Type 0x92 (146d)
0x03 Product Code See table below
0x04 Revision Dynamic (varies with the
communication firmware revision)
0x05 Status Dynamic
0x06 Serial Number 940000000…950000000
0x07 Product Name PowerMonitor 500
Part Number Name Product Code Description
1420-V1-ENT 146 - PowerMonitor 500 4 PowerMonitor 500 (240V ac, No I/O) Catalog Number 1420-V1-ENT
1420-V1P-ENT 146 - PowerMonitor 500 5 PowerMonitor 500 (240V ac, Digital I/O) Catalog Number 1420-V1P-ENT
1420-V1A-ENT 146 - PowerMonitor 500 6 PowerMonitor 500 (240V ac, Analog I/O) Catalog Number 1420-V1A-ENT
1420-V2-ENT 146 - PowerMonitor 500 7 PowerMonitor 500 (690V ac, No I/O) Catalog Number 1420-V2-ENT
1420-V2P-ENT 146 - PowerMonitor 500 8 PowerMonitor 500 (690V ac, Digital I/O) Catalog Number 1420-V2P-ENT
1420-V2A-ENT 146 - PowerMonitor 500 9 PowerMonitor 500 (690V ac, Analog I/O) Catalog Number 1420-V2A-ENT
