Rockwell Automation Publication 1420-UM001D-EN-P - September 2013
75
PowerMonitor 500 EtherNet/IP Device Profile
Appendix C
Request Parameters
Reset Types
The type of Reset requested can be any of the following.
Behavior
When the Identity Object receives a Reset request, it determines if the reset type
is supported, responds to the request, and executes the type of reset requested.
The Reset Service 1 restores the factory default settings for ACD.
Get Attribute Single Service
The Get Attribute Single service returns the single attribute specified by the
parameter Attribute ID.
Request Parameters
Identity Object Instances Besides the class instance (instance 0), the communication module’s Identity
Object supports the following instance.
Instance 1 (PowerMonitor 500 device and communication module)
Instance 1 represents the PowerMonitor 500 device with its EtherNet/IP
module. Instance 1 of the Identity Object is the one that is browsed by RSLinx
software, relevant to the complete device, that is, the PowerMonitor 500 device
and communication module.
Instance 1 of the Identity Object reports the following instance specific attribute
values.
Parameter Data Type Description
Type USINT Type of Reset to perform
Value Name Description
0 Power-Cycle Emulate as closely as possible cycling power on the item the Identity Object
represents.
1 Power-Cycle Emulate as closely as possible cycling power on the item the Identity Object
represents.
2…255 Reserved Reserved
Parameter Data Type Description
Attribute ID UINT Identifies the attribute to be read/returned
