List of Connectable Variables
The variables listed in this table can be connected to the following items:
• Analog outputs (all variables except energy values and run hour counter)
• Pulse outputs (only energy values)
• Alarm outputs (except energy, hour counter, and max values)
Housing DIN
Dimensions (WxHxD)
Module holder: 96 x 96 x 50 mm
‘A’ and ‘B’ type modules: 89.5 x 63 x 16 mm
‘C’ type module: 89.5 x 63 x 20 mm
Depth behind panel, max
81.7 mm
Material
ABS, self-extinguishing: UL 94 V-0
Mounting Panel
mounting
Pollution degree
2
Protection degree, front
(1)
IP65, UL type 4x indoor (NEMA4x indoor), UL type 12 (NEMA12), for use on flat surface of a Type 4X Indoor enclosure; for
use on flat surface of a Type 12 enclosure.
Protection degree, screw terminals
IP20
Weight, approx
400 g (0.88 lb) (packing included)
(1) Use with 60 or 70 °C copper conductor. Maximum surrounding air temperature 40 °C. The device shall be installed in a pollution degree 2 environment. Open Type Device. The terminals L1, L2, and L3 shall
be aquired by a circuit where devices or system, including filters or air gaps, are used to control overvoltages at the maximum rated impulse withstand voltage peak of 6.0 kV. Devices or system shall be
evaluated using the requirements in the Standard for Transient Voltage Surge Suppressors, UL 1449. Terminals tightening torque 0.79
N•m
(7 lb•in). The sum of the internal power consumption of the
assembled modules shall not be more than 5.3 W.
Table 40 - General Specifications
Attribute
Value
Table 41 - Power Supply Specification
Attribute
Value
Auxiliary power supply
90…260V AC/DC (48…62 Hz)
Power consumption
AC: 6 VA; DC: 3.5 W
Table 42 - Isolation Between Inputs and Outputs (1 minute)
Measuring Inputs
Relay Outputs
Communication
Port
Analog Outputs
Auxiliary Power
Supply
Measuring Inputs
-
4 kV
4 kV
4 kV
4 kV
Relay outputs
4 kV
2 kV
4 kV
4 kV
4 kV
Communication port
4 kV
4 kV
-
4 kV
4 kV
Analog Outputs
4 kV
4 kV
4 kV
0 kV
4 kV
Aux. power supply
4 kV
4 kV
4 kV
4 kV
-
TIP
Current inputs must be connected to external current transformers because the
isolation among the current inputs is just functional (100V AC).
