GuardShield Washdown Enclosures
Note: Note: The GuardShield washdown enclosures are
designed for use with standard GuardShield PAC light
curtains only.
Laser Alignment Tool
(used on standard GuardShield)
Weld Shields
The GuardShield PAC weld shields are sold as pairs.
These polycarbonate weld shields are designed as disposable
devices whose purpose is to protect the front window of the
GuardShield PAC from damage.
Dimensions [mm (in.)]
Cat. No.
PAC Enclosure Kit
440L-P4A3400YD 440L-AGST960
440L-P4A2500YD 440L-AGST640
12.9 (0.48)
19.05
(0.75)
4 (0.15)
62.48
(2.46)
66.8 (2.63)
Laser Alignment Tool (LAT)—
440L-ALAT
35.56 (1.4)
44.45 (1.75)
17.78
(0.70)
4.29 (0.169) hole dia.
81 x 2.66 (0.105) countersink
GuardShield PAC LAT Bracket
440L-AF6109
Requires 440L-AF6109 bracket to mount to front of GuardShield
PAC
49.5
(1.95)
L
37.3
(1.47)
R24
2X
10.16 (0.4)
3.0 (0.118)
Thick
R12 2X
GuardShield PAC Weld Shield
GuardShield PAC ArmorBlock Connectivity
Interconnecting Patchcords—
ArmorBlock I/O Connection
GuardShield PAC
Cat. No.
GuardShield
Weld Shield Cat. No.
Dimension “L”
[mm (in.)]
440L-P4A2500YD 440L-AGWS0640 655.3 (25.8)
440L-P4A3400YD 440L-AGWS0960 975.4 (38.4)
440L-P4AL2500YD 440L-AGWS0800 815.3 (32.1)
440L-P4AL2500YA
440L-P4AL3400YD 440L-AGWS1120 1135.4 (44.7)
440L-P4AL3400YA
Top View Color Pin No
Signal
Receiver
Brown 1 + 24V
White 2 OSSD 2
Blue 3 0 V
Black 4 OSSD 1
Gray 5 NC
Cat. No. Description
889D-F5ACDM-0M3 5-pin M12 patchcord, 12 inches
889D-F5ACDM-1 5-pin M12 patchcord, 1 meter
889D-F5ACDM-2 5-pin M12 patchcord, 2 meters
889D-F5ACDM-5 5-pin M12 patchcord, 5 meters
889D-F5ACDM-10 5-pin M12 patchcord, 10 meters
Ex a mple of P a tchcord
IMPORTANT
The GuardShield PAC pair with ArmorBlock
Guard I/O Connectivity has a five-pin M12
quick-disconnect connector on the receiver
wired to connect to the ArmorBlock five-pin
connector. The transmitter in that
GuardShield pair is a standard GuardShield
PAC transmitter with integrated laser
alignment system offered with a four-pin M12
quick-disconnect connector. It is possible to
connect either a standard four-pin M12
cordset or the five-pin M12 quick-disconnect
connector patchcord to this transmitter.
