GuardShield™ PAC Safety Light Curtain Installation Instructions
25
Original instructions
GuardShield PAC standard
Note: GuardShield PAC light curtains are sold in pairs. To select a transmitter or receiver, replace the “P” in the cat. no. with a “T” for the
transmitter and an “R” for the receiver.
GuardShield PAC with Integrated Laser Alignment
Note: GuardShield PAC with integrated laser alignment are sold in pairs. To select a transmitter or receiver, replace the “P” in the cat. no.
with a “T” for the transmitter and an “R” for the receiver.
GuardShield PAC with Integrated Laser Alignment and I/O Connectivity
Note: GuardShield PACs with ArmorBlock Guard I/O Connectivity are sold in pairs. The pair consists of a standard GuardShield PAC with
integrated laser alignment transmitter with 4 pin M12 quick-disconnect (440L-T4AXXXXYD). To select a receiver, replace the “P” in
the cat. no. with an “R” for the receiver.
Cat. No. Explanation
Cat. No. Beam Spacing No. of Beams Protective Height [mm (in.)]
440L-P4A2500YD 500 2 520 (20.4)
440L-P4A3400YD 400 3 820 (32.2)
Cat. No. Beam Spacing No. of Beams Protective Height [mm (in.)]
440L-P4AL2500YD 500 2 520 (20.4)
440L-P4AL3400YD 400 3 820 (32.2)
Cat. No. Beam Spacing No. of Beams Protective Height [mm (in.)]
440L-P4AL2500YA 500 2 520 (20.4)
440L-P4AL3400YA 400 3 820 (32.2)
440L - P 4 A X XXX Y D
Connector Option Micro QD
Environmental Rating IP65
PAC
Category Type 4
P - Pair, T - Transmitter, R - Receiver
Bulletin Number
Beam spacing (400mm or 500mm)
Number of beams (2 or 3)
440L - P 4 A L XXX Y A
Connector Option
–
Environmental Rating IP65
PAC
Type 4
P - Pair, T - Transmitter, R - Receiver
Bulletin Number
Beam spacing (400 or 500 mm)
L = Integrated laser alignment system
Number of beams (2 or 3)
X
– D for M12 QD and A for 5-pin M12 for ArmorBlock Guard I/O
