Rockwell Automation 193 193-5.0: Bulletin 913/592 SMP-3 Solid-State Overload Relay User Manual
Page 15

Chapter 3 – Installation and Wiring
3-5
Table 3.A Bulletin 109 Starter Dimensions (with SMP-3 Overload Relay)
➊
Contactor Cat. No.
A Width
B Height
C Depth
D
E
F
G
H
J ➋
K
100–A09, –A12
70
(2-49/64)
165.8
(6-17/32)
84
(3-5/16)
117.1
(4-5/8)
76.3
(3)
60
(2-3/8)
50
(1-31/32)
35
(1-25/64)
–15.7
(–5/8)
45
(1-13/16)
100–A18, –A24
70
(2-49/64)
174.4
(6-7/8)
92
(3-5/8)
122.4
(4-53/16)
87.1
(3-7/16)
75
(2-61/64)
60
(2-3/8)
35
(1-25/64)
–4.8
(–13/64)
55
(2-11/64)
100–A30
70
(2-49/64)
193.4
(7-19/64)
109
(4-19/64)
118
(4-21/32)
105.1
(4-9/64)
90
(3-35/64)
75
(2-61/64)
40
(1-9/16)
–7.4
(–19/64)
55
(2-11/64)
100–A38, –A45
90
(3-35/64)
217.2
(8-37/64)
125
(4-59/64)
114.8
(4-1/2)
124.1
(4-57/64)
100
(3-15/16)
NA
NA
55
(2-5/32)
–6.8
(–17/64)
75
(2-61/64)
100–A60, –A75
90
(3-35/64)
228.8
(9-1/64)
142
(5-19/32)
129
(5-3/32)
131.9
(5-13/64)
110
(4-11/32)
NA
NA
80
(3-5/32)
3.7
(5/32)
93
(3-21/32)
100–B110
119
(4-11/16)
311
(12-1/4)
155
(6-7/64)
158.8
(6-1/4)
176
(6-15/16)
130
(5-1/8)
NA
NA
100
(3-15/16)
13.9
(35/64)
119
(4-11/16)
100–B180
119
(4-11/16)
366
(14-13/32)
190
(7-31/64)
186
(7-5/16)
211.3
(8-5/16)
160
(6-5/16)
NA
NA
110
(4-21/64)
21.4
(27/32)
134
(5-9/32)
➊
Dimensions are shown in millimeters (inches). Dimensions are not intended for
manufacturing purposes.
➋
Note that a (–) dimension indicates reset is located to right of contactor reference.
