Accessories
24
5. 2
Welding Bosses
5.2.1
Welding Boss with Sealing Taper
Welding boss for flush mounting process connection with metallic sealing taper.
Material: AISI 316L
Fig. 12: 836E-NWT
5.2.2
Welding Boss with Sealing Surface
Welding boss for flush mounting process connection with sealing surface.
Material: AISI 316L
Seal (enclosed): silicone O-ring
Fig. 13: 836E-NWS
50
27.5
n
'
)3/
% .73
