P-4 Overview
PowerFlex SCR Bus Supply User Manual
Publication 20S-UM001G-EN-P
Catalog Number
Explanation
Important: PowerFlex SCR Bus Supply 1000A units with Master or Slave
configuration are available for 400/480 and 600/690 Volts.
Position Number
1-3 4 5-7 8 9 10
20S D 400 N E N
a b c d e f
a
Product
Code Type
20S PowerFlex SCR Bus Supply
b
Voltage Rating
Code Input Voltage Phase DC Output
D 400/480V AC 3 540 - 650V DC
F 600/690V AC 3 675 - 930V DC
c
Current Rating
Code Output
400 400A, 400/480V
600 600A, 400/480V
1k0 1000A, 400/480/600/690V
d
Enclosure
Code Rating Conformal Coating
N Open / IP00 No
e
Documentation & Shipping Carton
Code User Manual Carton
E English Yes
f
Configuration
Code Type
N Stand Alone
M Master (1000A only)
S Slave (1000A only)
