Configuring the Adapter 3-5
high portion (most significant digits) of the number and Parameter 12 -
[Device Inst Lo] to enter the low portion (always the three least
significant digits) of the number.
Figure 3.3 illustrates how to apportion
the Device Instance Number for entry into the adapter.
Figure 3.3 Apportioning the Device Instance Number for Entry
1. Enter the Device Instance Number using Parameter 11 - [Device
Inst Hi] and Parameter 12 - [Device Inst Lo].
Figure 3.4 Example Device Inst Hi/Lo HIM Screens
Table 3.B shows Device Instance Number examples to illustrate the
values needed to be entered for each parameter.
Table 3.B Examples of Device Instance Numbers
2. Reset the adapter (see Resetting the Adapter on page 3-9 ) to apply
the new Device Instance Number.
Device Instance
Number Parameter 11 -
[Device Inst Hi] Value Parameter 12 -
[Device Inst Lo] Value
14 0 14
328 0 328
2369 2 369
160000 (default) 160 0
4150732 4150 732
Device Instance Number
Most Significant Digits
Use Parameter 11 - [Device Inst Hi]
to enter value.
Least Significant Digits
Use Parameter 12 - [Device Inst Lo]
to enter value.
Device Inst Hi
Parameter: # 011
160
VALUE LIMITS SEL
Device Inst Lo
Parameter: # 012
0
VALUE LIMITS SEL
