3-2 Configuring the Adapter
Adapter parameters cannot be accessed using the integral keypad on a
PowerFlex 4-Class drive. You must use DriveExplorer or DriveExecutive
software, or an optional, external PowerFlex 4-Class HIM (22-HIM-A3
or 22-HIM-C2S). See
Figure 3.1 for styles. Basic steps to access
parameters in the adapter using the external HIM are shown in
Table 3.A . For additional HIM information, refer to the PowerFlex
4-Class HIM Quick Reference (publication 22HIM-QR001).
Table 3.A Accessing Adapter Parameters Using the HIM
Using the Optional, External PowerFlex 4-Class HIM
Step Example Screens
1. Power up the drive. Then plug the
external HIM into the bottom of the
drive. The Parameters menu for
the drive will be displayed.
2. Press key once to display the
Device Select menu.
3. Press (Enter) key to display
the DSI Devices menu. Press
Arrow to scroll to
22-COMM-B.
4. Press (Enter) key to select
the adapter. The Parameters menu
for the adapter will be displayed.
5. Press (Enter) key to access
the parameters. Edit the adapter
parameters using the same
techniques that you use to edit
drive parameters.
Parameters
Groups
Linear List
Changed Params
DIAG PARAM DSEL MEM SEL
Sel
Device Select
DSI Devices
DIAG PARAM DSEL MEM SEL
DSI Devices
PowerFlex 40
22-COMM-B
Parameters
Linear List
Changed Params
DIAG PARAM DSEL MEM SEL
Reset Module
Parameter: # 001
Ready 0
VALUE LIMITS SEL
