Getting Started 1-3
The adapter is compatible with Allen-Bradley PowerFlex 4-Class
(Component-Class) drives and other products that support an internal
DSI adapter. At the time of publication, compatible products include:
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
User-Supplied Equipment
To install and configure the adapter, you must supply:
Compatible Products
•
PowerFlex 4 drives (when used with DSI External Comms Kit)
•
PowerFlex 4M drives
(1)
(when used with DSI External Comms Kit)
(1) The 22-COMM-B adapter must have firmware version 1.003 (or later) to be compatible with
PowerFlex 4M drives.
•
PowerFlex 40 drives
•
PowerFlex 400 drives
Required Equipment
❑ One adapter
❑ One 15.24 cm (6 in.) Internal Interface cable
❑ One 3-pin linear plug (plugged into the adapter socket)
❑ One PowerFlex 4-Class DSI (Drive Serial Interface) Network
Communications Adapter Installation Instructions (publication
22COMM-IN002)
❑ A small flathead screwdriver
❑ A shielded, twisted wire pair to connect the adapter to the network
❑ A configuration tool, such as:
– PowerFlex 4-Class HIM (22-HIM-A3 or 22-HIM-C2S) – required
to access adapter parameters when not using DriveExplorer or
DriveExecutive software
– DriveExplorer software (version 3.01 or later)
– DriveExecutive stand-alone software (version 3.01 or later) or
bundled with the DriveTools SP suite (version 1.01 or later)
– Third-party network configuration software
