1336 FORCE™ To PowerFlex® 700S Phase II AC Drive Conversion Guide
28
PowerFlex 700S - Frame 10
No.
Name
Description
Wire Size Range
(1)(2)
(1)
Maximum/minimum sizes that the terminal block will accept - these are not recommendations.
(2)
Do Not exceed maximum wire size. Parallel connections may be required.
Torque
Terminal Bolt
Size
(3)
(4)
(3)
These connections are bus bar type terminations and require the use of lug type connectors.
(4)
Apply counter torque to the nut on the other side of terminations when tightening or loosening the terminal bolt in order to avoid damage to the terminal.
Maximum
Minimum
Recommended
1
Input Power Terminal Block
L1, L2, L3
(3)
Input power
300 mm
2
(600 MCM)
2.1 mm
2
(14 AWG)
40 N-m
(354 lb.-in.)
M12
2
Output Power Terminal Block
((3)
U/T1, V/T2, W/T3
Motor connections
300 mm
2
(600 MCM)
2.1 mm
2
(14 AWG)
40 N-m
(354 lb.-in.)
M12
3
SHLD Terminal, PE, Motor Ground
(3)
Terminating point for wiring shields
300 mm
2
(600 MCM)
2.1 mm
2
(14 AWG)
40 N-m
(354 lb.-in.)
M10
4
DC Bus
(3)
(2 Terminals; DC–, DC+)
DC input or external brake
300 mm
2
(600 MCM)
2.1 mm
2
(14 AWG)
40 N-m
(354 lb.-in.)
M12
5
Cable Clamp for Shield
DANGER
DANGER
DC BUS CONDUCTORS AND CAPACITORS
OPERATE AT HIGH VOLTAGE. REMOVE POWER
AND WAIT 5 MINUTES BEFORE SERVICING
Cat No.
1234567890-*
1234567890-*
FIELD INSTALLED OPTIONS:
FIELD INSTALLED OPTIONS:
DC-
DC+
L1
L2
L3
U/T1
V/T2
W/T3
2
1
5
4
3
