Preface
Purpose of This Manual
This manual provides installation instructions and connection and configuration
information for the PowerFlex® DC Stand Alone Regulator (SAR) and the Gate
Amplifier. It is intended for internal Rockwell Automation use only.
What This Manual Contains
This user manual contains the following sections:
• Description of the SAR and Gate Amplifier products and general
integration information
• Installation, connection and configuration instructions for the SAR
• Installation and connection instructions for the Gate Amplifier
• Guidelines for retrofit installations with DC power modules
• SAR and Gate Amplifier specifications
• Specifications for additional components and cables used with the SAR
and Gate Amplifier products
Drawing Numbers
Throughout this manual, drawings are identified by an eight-digit number, for
example, 99999999. Where a drawing number includes an asterisk (*) in the 8th
digit, the “*” represents the latest version number of the drawing, for example,
999999*.
Additional Resources
These documents contain additional information concerning the PowerFlex DC
Stand Alone Regulator and related Rockwell Automation products.
You can view or download publications at
. To order paper copies of technical documentation, contact your local
Rockwell Automation distributor or sales representative.
Resource
Description
D-UM001
Provides additional installation, configuration,
and programming information for the Stand
Alone Regulator.
Industrial Automation Wiring and Grounding
Guidelines, public
70-4.1
Provides general guidelines for installing a
Rockwell Automation industrial system.
Product Certifications website,
Provides declarations of conformity, certificates,
and other certification details.
