REPLACING A DRIVE - 178
WD SHARESPACE
USER MANUAL
3. Place the enclosure on a flat, stable surface.
4. Observe ESD precautions when handling a system component.
5. Remove the system cover.
(a) Loosen the two captive screws on the rear of the system cover.
(b) Slide the cover towards the back of the system until the tabs on the cover disengage from the
slots on the unit.
(c) Lift the cover to remove it, and then set it aside.
Note: The drive number is stamped to the left of the drive.
6. Remove the failed drive from the drive bay.
WARNING! When pulling out the hard drive (as was listed) using the
mounting rails handle, use your hand to support it from underneath so it
does not fall.
(a) Pull on the center of the mounting rails handle and move the assembly from side to side to
disengage the side latches. Carefully slide the drive out 1 inch from its bay.
