Operating Manual Light Control „PULSE HFMD / PULSE PIR - Vers. IV“ ENG
Presence range
Function for setting the detection
range of the presence sensor.
By default, the range for the pres-
ence sensor is set to 80%.
6 different levels from 10% to
100% can be set.
The function can only be changed
on
- Lights equipped with HFMD
sensor
Note: For lights equipped with PIR
sensor, the range can be changed
by turning the sensor ball (see in-
structions for use of the light.
Loading setting level 4
Actuation Display
Light bar LED 1 (dark green)
Parameterisation mode ON
Displaying the presence range
Setting functions 4.1 to 4.6
Loading the parameterisation mode
Light bar LEDs 1+2+3+4
Level 4
Light bar LEDs 1-6
some are flashing
10 %
20 %
40 %
60 %
80 %
100 %
Press both keys again
three times
for 5 seconds each
Press both keys
for at least 10 seconds
3 x
Continued >
Release both keys
