Operating Manual Light Control „PULSE HFMD / PULSE PIR - Vers. IV“
ENG
Changing the parameterising functions (Continued)
Fig. 3
LED 1 2 3 4 5 6
Fig. 6
Key I
Light
bar
Key II
Actuation
Consequence
Changing the function
The desired function can be
loaded by pressing key II.
Press key II as often as
necessary for reaching the
desired function.
n x
The LED valid for the function will
be lit or flash on the light bar:
LED 1
Function x.1
LED 2
Function x.2
LED 3
Function x.3
LED 4
Function x.4
LED 5
Function x.5
LED 6
Function x.6
LEDs 5+6
Function x.7
