30
Operating Manual Light Control „PULSE HFMD / PULSE PIR - Vers. IV“ ENG
Loading setting level 2
Actuation Display
Light bar LED 1 (dark green)
Parameterisation mode ON
Light bar LEDs 5+6
Function 2.7
Changing the function from ON to OFF or vice versa
Setting function 2.7
LED changes from constantly lit
to flashing or vice versa:
- constant = Function ON
- flashing = Function OFF
Press key II 6 times
Loading the parameterisation mode
Light bar LEDs 1+2
Level 2
Press both keys again
for 5 seconds
Special function
The special function cannot be
used.
The function cannot be changed.
Press both keys
for at least 10 seconds
6 x
n x
Press key I as often as
necessary for reaching
the desired value
Function 2.7 Special function
