Part Numbering (Cont.)
* ConverterPAC options
B Booster module S Trimpot removed for external
D DC OK or Power Good 1 BatPAC adjustment
F Full 50-110% output adjustment
2
T 90-110% output adjustment
4
F1 50-107.5% output adjustment T1 90-107.5% output adjustment
F2 50-105% output adjustment T2 90-105% output adjustment
F3 50-102.5% output adjustment T3 90-102.5% output adjustment
F4 50-100% output adjustment T4 90-100% output adjustment
F5 60-110% output adjustment T5 98-105% output adjustment
F6 70-110% output adjustment T6 100-110% output adjustment
F7 80-110% output adjustment V1 "VXI" low noise (150 mV or less)
I Industrial Grade module 15V< V
OUT
≤ 24 V
5
K Custom SRF module used V2 "VXI" low noise (50 mV or less)
P Preload V
OUT
≤ 15 Vdc
M Military Grade module V3 “VXI” low noise (1% ripple or less)
R RAM external
3
V
OUT
> 24 V
Examples:
M15V/10A, M15V/10ADFI, D15V/6.7A-12V/8.3AT
M = ModuPAC (RoHS =GM) R = RAMPAC (RoHS = GR)
D = DualPAC (RoHS = GD) B = BatPAC (RoHS = GB)
J = JuniorPAC (RoHS = GJ) PZ = PZ - FinPAC (RoHS = GPZ)
[1] D option: Optional for all ConverterPACs EXCEPT the DualPAC, BatPAC and RamPAC
[2] F options: Optional for all ConverterPACs EXCEPT the BatPAC, DualQPAC, and FlexPAC. Trim range
dependent on module type and voltage
[3] R option: When using an external RAM, components such as autosense resistors and local sense
jumpers must be removed before turning on the supply. In addition, in order to insure proper operation,
sense pins must be connected either locally or remotely after the RAM's output. For further information,
contact Applications Engineering.
[4] T options: Optional for all ConverterPACs EXCEPT the BatPAC, DualQPAC, and FlexPAC. Trim Range
dependent on module type and voltage
[5] V options: Optional ONLY on the ModuPAC, DualPAC and JuniorPAC. N/A on all other
ConverterPACs. Requires 15% minimum load.
FlexPAC Fxxaaa-bbb-ccc-ddd
F = FlexPAC
xx = pack chassis variations
aaa = voltage setting for output 1 with implicit factor of 10 (103 = 10.3 V)
bbb = output 2
