background image

UG:105

vicorpower.com

Applications Engineering: 800 927.9474

Page 23

Specifications

Input Characterisitcs

Input Voltage

85-264 Vac, 47-500 Hz 100-380 Vdc

Power Factor

0.99 @ 115 Vac ; 0.95 @ 230 Vac - both at full load (47-63 Hz)

Inrush Current

25A pk @ 115 Vrms and 230 Vrms

Ride Through Time

>20 ms at nominal line, full load

Power Fail

>3 ms warning

Conducted EMI

FCC Class A; EN55022 Class A (Certain configurations meet B. Contact Factory)
Mil-STD 461 CE 101 and 102 require external filtering

Surge Immunity

EN 61000-4-5 Installation Class 3, Performance Criteria B
(Temporary loss of output power may occur which is self recoverable)

Dielectric Withstand

Primary to Chassis GND = 2,121 Vdc
Primary to Secondary = 4,242 Vdc
Secondary to Chassis GND = 750 Vdc

Overvoltage and Transients

Per Mil-STD 704 and 1399 (MI rugged chassis only

Ouput Characterisitcs

Line/Load Regulation

Ist Gen: ± 0.2% max.10% to full load
± 0.5% max. No load to 10% load

Line Regulation*

Maxi: ± 0.20% max. to 0.3% max LL to HL, Full Load

Load Regulation*

Maxi: ± 0.1% No load to full load

VI-200/VI-J00 Setpoint
Accuracy*

1% for standard voltages; 2% for special or adjustable voltages

Maxi Setpoint Accuracy

1% for standard voltages;
2% for special, adjustable voltages and 48 Vdc outputs

Ripple and Noise

Std. outputs: 2% or 100 mV p-p, whichever is greater, 75% min. load;
VXI options: V1 = (150 mVp-p or less) 15 V < Vout < 24 V outputs
V2 = (50 mVp-p or less) Vout < 15 Vdc
V3 = (1% ripple or less) Vout > 24 V
(VXI options require 15% minimum load)
RAMPAC: 10 mVp-p or 0.15% whichever is greater
FlexPAC 50 mV p-p

External Output Trim Range
(Using Trim/Sc pin)

10% -110% of nominal voltage Maxi modules
50% -110% of nominal voltage VI-200/VI-J00 modules
90% -110% of nominal voltage VI-200/VI-J00 modules 10-15 V
2-25 V FlexPAC

Overcurrent Trip Point

105-125% of full load capability of VI-200/VI-J00 modules
115% typical of full load capability of Maxi modules
135% FlexPAC

Overvoltage Protection

115-135% on VI-200 and Maxi modules only

Efficiency

80% typical

Output Power

MP Prefix

MX Prefix

1,600 W at 230 Vac

2,400 W at 230 Vac

1,200 W at 115 Vac

+

1,200 W at 115 Vac

+

*Note: Not to exceed an input current of 15 A.
