Page 38
Door
Preparation
3.38
2014 (BOOK SIZE)
Shop 3
Doorlite and Designline
Panel Installation
Wrought Iron Doorlite
Part # CCRSCREW
Impact Doorlite
Part # SCCCA150
Flush Fit Doorlite
Part # SCDL100
For this lite
Use this fastener
Select the Right Screw
Use the correct screw with the appropriate lite frame. (Fasteners are shown actual size.)
