Therma-Tru SHOP 3 Door Preparation - Book Size - Manual (Page 15)

Door
Preparation
Shop 3 2014 (BOOK SIZE) 3.15
Top Edge
First
Hinge
Second
Hinge
Third
Hinge
Fourth
Hinge
(Doors
over 7/0)
DIMENSIONS FROM TOP EDGE OF DOOR TO
TOP OF HINGE MORTISES.
(Index from top edge of door)
Mark top of hinge mortises.
Door Slab
First
Hinge
Second
Hinge
Third
Hinge
Fourth
Hinge
6/6 Standard
6/8 Standard
7/0 Standard
8/0 Standard
8.344”
5.219”
37.594”
30.719”
66.844”
56.219”
N/A
81.719”
HINGE 1 HINGE 2 HINGE 3 HINGE 4
6/8 DOOR 8.525 37.775 67.025 N/A
8/0 DOOR 5.431 30.931 56.431 81.931
DESCRIPTION
HINGE LOCATION (TOP DOWN)
ADJUSTABLE HINGE
Hinge Preparation
(Except 90 Minute Steel Fire Door)
