M

ark

901 S

erieS

C

avity

-F

illed

B

all

v

alveS

o

rderIng

s

cheMatIc

MK901/0714

Model Number

901HN

Hand Operated

901DA

Double Acting Pneumatic Actuator

901SR

Spring Return Pneumatic Actuator

901MO

Motor Operated

Size

050

1/2" (DN15)

075

3/4" (DN20)

100

1" (DN25)

150

1-1/2" (DN40)

200

2" (DN50)

250

2-1/2" (DN65)

300

3" (DN80)

400

4" (DN100)

Body Material

6L

A351 CF3M 316L

1

End Connections

C

PTFE Cavity Filler

Z

Non-Standard

2

End Features

A

Tri-Clamp / SF1

B

Extended Tube End / SF1

C

Tri-Clamp x Extended Tube End / SF1

H

Extended Tube x Tri-Clamp / SF1

Z

Non-Standard

3 & 4

Operation

HL

Lever (Standard)

P1

UT-0A-DA STD

P2

UT-0-DA STD

P3

UT-1-DA STD

P4

UT-2-DA STD

P5

UT-2.5-DA STD

P6

UT-3-DA STD

P7

UT-3.5-DA STD

P8

UT-4-DA STD

PF

UT-4.5-DA STD

P9

UT-5-DA STD

S1

UT-0-SR STD

S2

UT-1-SR STD

S3

UT-2-SR STD

S4

UT-2.5-SR STD

S5

UT-3-SR STD

S6

UT-3.5-SR STD

S7

UT-4-SR STD

SF

UT-4.5-SR STD

S8

UT-5-SR STD

NN

None

ZZ

Non-Standard

Model

Size

Body Mat'l

1

2

3

4

5

6

5 & 6

Actuator Pressure

40

40 psi

60

60 psi

80

80 psi

NN

N/A (no pneumatic actuator)

ZZ

Non-Standard

7 & 8

Solenoid Feature

Actuator

Type

1A

110 VAC Motor

MO

3A

3W 8551-120VAC N4 UT-0/5

SR

3C

3W EF8551-120VAC N7 UT-0/5

SR

3J

3W 8317G35-120VVAC N4 UT-0/2.5

SR

3M

3W 8321G1-120VAC N4 UT-3/5

SR

3Q

3W EF8317G35-120VAC N7 UT-0/2.5

SR

3R

3W EF8321G1-120VAC N7 UT-3/5

SR

4A

4W 8551-120VAC N4 UT-0A

DA

4B

4W 8551-120VAC N4 UT-0/5

DA

4D

4W EF8551-120VAC N7 UT-0A

DA

4E

4W EF8551-120VAC N7 UT-0/5

DA

ZZ

Non-Standard

9 & 10

Limit Switch

AA

LS FMYB-5120-N4 to UT-0/3

AB

LS FMYB-5120-N4 to UT-3.5/7

AC

LS AMYB-5120-N7 to UT-0/3

AD

LS AMYB-5120-N7 to UT-3.5/7

AE

LS AMYB-5120-N4 to Valve

AF

LS-AMYB-5120-N7 to Valve

0Z

Non-Standard

11 & 12

Fail Position

NN

Fail Position N/A (No "SR" Actuator)

01

Fail Closed

02

Fail Open

13 & 14

Positioner

AA

Siemens 760P (3-15 psi), for UT-0/3

AB

Siemens 760P (3-15 psi), for UT-3.5/7

AC

Siemens 760E (4-20 mA), for UT-0/3

AD

Siemens 760E (4-20 mA), for UT-3.5/7

AE

Siemens 2-IQ (4-20 mA), for UT-0/3 DA

AF

Siemens 2-IQ (4-20 mA), for UT-3.5/7 DA

AQ

Siemens 2-IQ (4-20 mA), for UT-0/3 SR

AR

Siemens 2-IQ (4-20 mA), for UT-3.5/7 SR

ZZ

Non-Standard

15

Miscellaneous Features

1

2-Bug Screen 1/8" SST

2

2-Speed Control 1/8" (4-Way)

3

SST Tube & Fittings F/Automation

4

AFR 4Z030A to UT-0.2 SST

Z

Non-standard
