Model
JSHM J Series Hand Metering Valve
Model
—
Size
—
Material
1
1&2 3&4 5&6 7&8 9&10 11&12 13&14 15
Size
050 1/2" (DN15)
075 3/4" (DN20)
100 1" (DN25)
150 1-1/2" (DN40)
Body Material
6L ASTM A479, 316L
1 & 2 Body Feature
AT Angle Body ASME BPE Tri-Clamp
AB Angle Body ASME BPE BWE
PT FNPT
TC ASME BPE Tri-Clamp
TE ASME BPE Tube Weld
ZZ Non-Standard
3 & 4 Trim - FDA & USP Class V
1S Cv 0 - 0.4 (1/2" - 3/4" only)
2S Cv 0 - 0.7 (1/2" - 3/4" only)
3S Cv 0 - 1.5 (1/2" - 3/4" only)
4S Cv 0 - 3.5 (1" - 1-1/2" only)
ZZ Non-standard
JSHM S
erieS
H
and
M
etering
V
alVeS
o
rDering
s
ChematiC
JSHM/0514
5 & 6 Seat Material - FDA & USP Class VI
TF PTFE
PK PEEK
ZZ Non-Standard
7 & 8 Range
00 None
13 & 14 SEP Compliance
0G SEP Compliant (1/2" - 1" ONLY)
0F PED Compliant (1-1/2" ONLY)
00 None
ZZ Non-Standard
15 Accessories
S Clean For Oil Free
X Clean For Oxygen
0 None
Z Non-Standard
11 & 12 Actuator
SK Standard Actuator
AK
Standard Actuator / Autoclavable Anod.
Aluminum Knob
ZZ Non-Standard
9 & 10 Diaphragm Material
JL Jorlon PTFE, FDA & USP Class VI
ZZ Non-Standard
Model
JSHM J Series Hand Metering Valve
Model
—
Size
—
Material
1
1&2 3&4 5&6 7&8
Size
050 1/2" (DN15)
075 3/4" (DN20)
100 1" (DN25)
150 1-1/2" (DN40)
Body Material
6L ASTM A479, 316L
Kit
Kit
o
rDering
s
ChematiC For
r
epair
K
it
3 & 4 Seat Material
TF PTFE
PK PEEK
1 & 2 Trim - FDA & USP Class V
1S Cv 0 - 0.4 (1/2" - 3/4" only)
2S Cv 0 - 0.7 (1/2" - 3/4" only)
3S Cv 0 - 1.5 (1/2" - 3/4" only)
4S Cv 0 - 3.5 (1" - 1-1/2" only)
ZZ Non-standard
5 & 6 Diaphragm Material
JL Jorlon
ZZ Non-Standard
7 & 8 Accessories
0S Clean for Oil Free
0X Clean for Oxygen
00 None
ZZ Non-Standard
