INSTALLATION INSTRUCTIONS FOR 2010+ FORD F-150
RAPTOR 6.2L SUPERCAB OR SUPERCREW HEADERS
Thanks for purchasing Stainless Works Muscleflow Headers for your Ford F-150 Raptor.
We have gone to great pains to make sure that our exhaust systems fit and sound great.
Please follow these steps to ensure that your installation goes as planned.
1. Stainless Works recommends the use of Hi-Temp RTV silicon gasket maker as an option
to or in conjunction with the use of factory gaskets. The recommended RTV is Sensor-
Safe Valco All-in-one Aluminum or Permatex P/N 101BR or 27BR, available at NAPA
and other retailers.
2. Disconnect the battery before starting work on the exhaust system for your vehicle.
3. Your exhaust system can be installed by a weekend warrior but the use of a lift is
recommended for ease of installation. If using a jack, the vehicle must be placed on a
level hard surface and jack stands are required for safety reasons.
DISASSEMBLY
4. Raise and support the vehicle.
5. Remove the air box and inlet.
6. Remove engine skid plates (10) 10 mm bolts.
7. Loosen the factory exhaust at the 2 bolt flange (2) 10 mm bolts.
FOR CONNECTION TO FACTORY EXHAUST
8. Loosen clamp at slip fit connection point (behind the 2 bolt flange connection
point) and remove the front section of pipe between the 2 bolt flange connection
and the slip joint.
FOR CONNECTION TO STAINLESS WORKS EXHAUST
9. Remove exhaust from all hangers then remove from truck.
10. Remove skid plate on left side of transmission cross member, (4) 8 mm bolts.
11. The following instructions are required only if you are planning to save the factory
exhaust, otherwise skip to line #21
