2005+ DODGE HEMI MAGNUM, CHARGER AND 300C EXHAUST SYSTEM
INSTALLATION INSTRUCTIONS

Thanks for purchasing a Stainless Works exhaust system for your Hemi Magnum, Charger or
300C. We have tried to include all the information you will need to install the exhaust system.
Please contact us at 800-878-3635 if you have any questions.

1. Let car cool completely and exhaust cool to the touch before starting any work.
2. Remove the factory exhaust system starting at the rear of car. Be careful as the factory

system is very heavy and will need to be supported during removal.

3. Install x pipe and 2 clamps onto factory headpipes-the long legs of the x pipe will be the

outlet side of the x pipe-the short legs slip over the factory headpipes.

4. Install one clamp over each muffler inlet, and install mufflers onto x pipe outlet. The

muffler inlets will be 2 ½” inside diameter and are designed to slip OVER the x pipe
outlet. The hangers will need to be slipped over the muffler outlets-the left hanger for the
rear of the muffler is the one different style hanger-it looks like a tight “s” when viewed
from the rear of the car. A picture is below for clarity:


5. Slip two more clamps over the front tailpipes, and slip over muffler outlets. Install

hangers in respective positions. Install two clamps onto rear tailpipes, and slip over front
tailpipes outlets.
