17. Remove the OEM lower links & replace the OEM lower links with the

new Skyjacker extended lower links (One side at a time). (See Photo

# 10)

Note: Only start these bolts & nuts, do not tighten at this time.

Once both lower links are installed, tighten each lower link being sure

to realign the marks on the eccentric cams.

18. Place a jack under the OEM transfer case crossmember & remove

the four screws that mount the transfer case pivot assembly from the

body of the vehicle.

Note: It will be necessary to roll the floor mat

back to gain access to the OEM bolts.

19. Remove the three bolts on each side of the

transfer case skid plate & lower it down enough to

install the new Skyjacker square tube spacers

between the skid plate & the frame.

Note: 97-02

TJ models use the 1/2" x 3" flat socket head

tapered bolts supplied & 03-06 TJ models will use

the 12mm x 80mm flat socket tapered head bolts

supplied. Apply a few drops of supplied thread

lock compound on the bolt threads prior to

installing. Tighten the bolts to 75-80 ft.lbs. (See

Photo # 11)

Note: On 03-06 TJ models equipped with an engine skid plate,

remove the two engine skid plate bolts. Install the small square

tube spacers at the mounting points on the frame rails, along

with the 12mm bolts supplied.

20. Install the new Skyjacker transfer case linkage pivot drop

bracket to the OEM pivot bracket using the OEM hardware.

Using the two 1/4" x 1" bolts with a flat washer & self-locking

nut, bolt the ball swivel bracket (See Arrow in Photo # 12) to

the new Skyjacker drop bracket

Note: The bracket has two sets of

holes. The bottom holes are for 4" lifts as shown & the upper holes

are for 2 1/2" lifts. Placing the pivot bracket back in location & start

the end of the rod through the ball swivel. Bolt the bracket back into

location with the OEM hardware. (See Photo # 13)

Rear Installation:

1. Place a floor jack under the rear axle & raise the vehicle. Place jack

stands under the frame ahead of the lower link bracket to support the

vehicle.

2. Remove the rear tires & OEM rear shocks.

3. Remove the OEM rear track bar & OEM sway bar end link bolts at the axle.

I-TJ4013B

Pg 6

Photo # 10

Photo # 11

Photo # 12

Photo # 13
