SECTION OM – OPERATOR’S MANUAL
Form # 169365
OM-7
Issue – May 2008
3.4 TOWING ONE-AXLE AND TWO-
AXLE TRANSPORTERS WITH M
SERIES WINDROWER TRACTOR
The one-axle and two-axle MT8 Header
Transporters can be towed with the MacDon M
Series Windrower Tractor provided that the
MacDon Transporter Adapter Hitch (B5247) is
attached to the tractor.
CAUTION
Towing the Transporter without a header
on the Transporter is not recommended
because of the lack of sufficient weight
on the tractor drive wheels for safe
operation of the tractor.
CAUTION
If necessary to tow the Transporter
without a header on the Transporter, do
not operate tractor at typical road speed.
Proceed with caution.
3.4.1 Attaching Adapter Hitch to
Windrower Tractor
a. Remove clevis pins from hitch.
b. Start tractor and lower windrower lift legs fully
and approach hitch.
c. Line up legs with pockets in hitch and drive
forward until legs fully engage hitch.
d. Rotate stops against legs and insert clevis
pins. Secure with hairpins.
e. Attach safety chain on hitch to center link
mounting bracket on tractor frame. Leave
some slack in chain to allow hitch to be raised
to maximum height of lift linkage. Secure
chain with locking device.
f. Connect wiring harness from hitch to tractor.
