SECTION OM – OPERATOR’S MANUAL
Form # 169365
OM-4
Issue – May 2008
2 SPECIFICATIONS AND WEIGHT DATA
2.1 SPECIFICATIONS
NOTES:
1. Specifications and design are subject to change without notice or obligation to revise previously sold
units.
2. Ensure that truck and truck hitch are rated for maximum gross weight and maximum hitch load.
Hitch loads require a suitably sized truck.
3. Ensure that truck and truck hitch are rated for maximum gross weight.
4. Requires electric brake controller to be installed in truck.
SPECIFICATION
ITEM
MT8-1 MT8-2 MT8-3
AXLES One Two Three
MAX GROSS TRANSPORT WEIGHT 8000 lb (3620 kg) 12000 lb (5430 kg) 14000 lb (6335 kg)
LENGTH 467 in. (11866 mm)
468-563 in.
(11891-14301 mm)
580-617 in.
(14730-15673 mm)
WIDTH 100.75 in. (2560 mm)
TREAD WIDTH 88 in. (2235 mm)
WEIGHT 2613 lb (1182 kg) 3255 lb (1473 kg) 3755 lb (1699 kg)
MINIMUM HITCH LOAD 2000 lb (905 kg) 3000 lb (1375 kg) <100 lb. (45 kg)
TIRES ST225/75 R15 LR D
Pressure 65 psi (448 kPa)
MAX HEADER SIZE 30 ft D Series 40 ft D or FD Series 45 ft D or FD Series
SUSPENSION Flex Torsion Axle
ADJUSTABLE CUTTERBAR SUPPORTS Two Two Two or Three
TOWING VEHICLE
Truck, M Series Windrower Tractor
(See Note 2)
Truck, M Series
Windrower Tractor,
Combine
(See Note 3)
TOWING SPEED Highway
BRAKES Electric Drum on All Wheels (See Note 4)
FENDERS Each Wheel
