U
SER
’
S MANUAL
PHL1300
TERMINAL
/ IRU1300
CRADLE
5
When you remove the packing, please check
for any physical damage. We recommend that
you save all packing material, as it should be
used whenever you need to ship your terminal
(eg. for service). Damage due to improper
repacking is not covered by the warranty.
Apart from the terminal or cradle, additional
items might be ordered and supplied.
If there are any missing parts please contact
your supplier.
Do not remove the label !
On the back of every unit you will find a label.
The label is attached by the manufacturer and
includes information about the function it
supports and a serial number.
Do not remove it.
PHL1300:
Terminal
Backup battery
Handstrap
ADDITIONAL
PHL1300:
Battery pack
INSTALLATION
3
2
2.1 UNPACKING
IRU1300:
Cradle
ADDITIONAL
IRU1300:
Power Supply
RS232 cable DB9 F
RS485 network cable
