Opticon PHL 1300 - Manual (Page 18)

6.1.2 Optical specifications
Light source 650 nm visible laser diode
Scan rate 100 scans/sec
Decode rate 100 decodes/sec
Reading width min. 40 mm.
Resolution at PCS 0,9 : 0.15 mm (6mil)
Min. PCS Values 0.45
Depth of field 70 - 380 mm
(at PCS 0.9, res. 1.0 mm)
6.1.3 Supported symbologies
Chinese Post 2of5
Codabar incl. ABC and CX
Code 39
Code 93
Code 128
EAN-8 incl. +2,+5
EAN-13 incl. +2,+5
IATA
Industrial 2of5 -
Interleaved 2of5
Italian Pharmaceutical
Laetus
Matrix 2of5
MSI/Plessey
UK/Plessey
S-Code
Telepen
UPC-A incl. +2,+5
UPC-E incl. +2,+5
6.1.4 Functionality
Memory ROM: 32 kB
FlashROM:(O/S and program)
2 x 256 kB (total 512 kB)
fast RAM: 2 kB
RAM (data storage):
8 MB battery backed up D-RAM
Microprocessor 16-bit
Real time clock Quartz RTC, time and date
programmable, leap year handling,
(accuracy + 60 sec./month)
Display 96x64 Pixels
graphic LCD with backlight
Character fonts:
5/10 lines x 16 characters
U
SER
’
S MANUAL
PHL1300
TERMINAL
/ IRU1300
CRADLE
18
6.1.1 Electrical specifications
Main battery Lithium-Ion rechargeable
(Opticon item)
Alkaline AA-size batteries
(optional user item)
Main battery Li-Ion: When making every 5
operating time seonds 1 scan with 1 sec
laserbeam on and 0.2 sec.
green LED on and 0.2 sec.
buzzer on, operating time is:
approx. 36 hours
Alkaline: When making every 5
seonds 1 scan with 1 sec
laserbeam on and 0.2 sec.
green LED on and 0.2 sec.
buzzer on, operating time is:
approx. 78 hours
Different operation conditions
affect the operating time
Backup battery Lithium CR2032
Backup battery
operating time
3 weeks backup time
Battery Low voltage indicated on
management the terminal display.
When battery is low the
switches off automatically.
Charging method Recharging Lithium-Ion pack in
terminal via cradle
SPECIFICATIONS
3
6
6.1 SPECIFICATIONS TERMINAL
