2.5.1 Required batteries
The terminal needs both main battery and
backup battery for operation.
Main Battery
The main battery can consist of:
Rechargeable Opticon battery pack (Li-Ion),
to be recharged when placing the terminal
PHL1300 in the cradle IRU1300.
This battery is supplied with the terminal
and is recommended by Opticon.
Pen lite batteries.
Batteries that are not supplied by Opticon
must be AA-size and absolutely leakproof.
If rechargeable batteries are used, they
need to be recharged by a separate
battery charging device.
Backup Battery
Use only one type of battery for backup:
Backup cell:
CR2032 Li (Lithium, button type).
2.5.2 How to charge the rechargeable
battery pack in the cradle?
Make sure that the Opticon rechargeable
battery pack is inserted in the terminal.
If the terminal with the battery pack is placed
in the cradle, the LED on the cradle will turn
green.
When the terminal is placed in the cradle, the
rechargeable battery pack will be charged
automatically for 8 hours.
2.5.3 When to replace or recharge the
main battery?
There are 2 reasons for replacing the main
battery;
as soon as possible after the battery
indicator
appears on the display.
when you are not using the terminal for an
extended period.
2.5.4 When to replace the backup battery?
When low battery mark
appears,
replace the battery without delay.
2.5.5 How to (re)place the main battery
in the terminal?
Only use batteries as specified in
paragraph 2.5.1.
If you have data stored, make sure the
backup battery is placed and full
enough, to avoid data loss.
Unlock main battery case cover: (ref. 1)
Unlock the case cover by use of a flat
screwdriver or a coin.
Remove old battery by simply taking out.
Installing Opticon battery pack: (ref. 2)
Follow the instructions on the label.
Installing penlite batteries: (ref. 3)
Make sure you use the right battery size.
Place 2 batteries in the battery holder
aligning plus (+) and minus (-) ends as
shown inside the battery compartment.
Lock main battery case cover:
Position the case cover and fix its position
by screwing hand tight.
!
!
