page
1 INTRODUCTION 4
2 INSTALLATION 5
2.1 U NPACKING 5
2.2 D ETAILED VIEW 6
2.2.1 Dimensions of terminal 6
2.2.2 Details of terminal 7
2.2.3 Dimensions of cradle 8
2.2.4 Details of cradle 8
2.3 H ANDLING PRECAUTIONS 9
2.4 A SSEMBLY 10
2.4.1 Terminal 10
2.4.2 Cradle 10
2.4.3 Terminal on cradle 10
2.5 I NSTALLING , REPLACING AND CHARGING
BATTERIES 11
2.5.1 Required batteries 12
2.5.2 How to charge the rechargeable
battery pack in the cradle?
12
2.5.3 When to replace or recharge the
main battery?
12
2.5.4 When to replace the backup
battery?
12
2.5.5 How to (re)place the main battery
in the terminal?
12
2.5.6 How to (re)place the backup battery
in the terminal?
13
2.6 I NSTALLING IN A SYSTEM 14
2.6.1 Single cradle 14
2.6.2 Cradle network 14
2.6.3 Dip switch settings on cradle 15
3 OPERATION OF THE TERMINAL 15
4 SCANNING 16
4.1 How to read the barcode 16
4.2 Barcode reading problems 16
U
SER
’
S MANUAL
PHL1300
TERMINAL
/ IRU1300
CRADLE
3
page
5 PIN OUT 17
5.1 RS232 cable for cradle 17
5.2 RS485 cable for cradle network 17
6 SPECIFICATIONS 18
6.1 S PECIFICATIONS T ERMINAL 18
6.1.1 Electrical specifications 18
6.1.2 Optical specifications 18
6.1.3 Supported symbologies 18
6.1.4 Functionality 18
6.1.5 Environmental specifications 19
6.1.6 Physical specifications 19
6.2 S
PECIFICATION
C
RADLE
19
6.2.1 Electrical specifications 19
6.2.2 Functionality 19
6.2.3 Environmental specifications 19
6.2.4 Physical specifications 19
7 TROUBLESHOOTING 20
7.1 C OMMUNICATION PROBLEMS 21
7.2 R EAD OPERATION PROBLEMS 21
7.3 T ERMINAL PROBLEMS 22
8 PRODUCT ORDERING
INFORMATION 23
CONTENTS
