MTS SWIFT 50 GLP Sensor User Manual
Page 32
SWIFT 50 GLP Sensors Installation
32
Road and Track Vehicles
Installing the Transducer
Do not allow the mounting arm or anti-rotate arm to bump against any
portion of the wheel or wheel well.
Any jarring of the mounting arm or anti-rotate arm will damage the slip ring
and/or the encoder.
Position the mounting arm and anti-rotate assembly so that full suspension travel
will not cause interference with the wheel well or any other part of the vehicle.
CAUTION
