Page 46: Understanding projects 46
MTS Series 793 Controller Overview
About Projects
Operation Concepts
46
About Projects
Understanding Projects
A Series 793 Project folder (or Project for simplicity) contains the various types
of information you typically acquire while testing.
Projects are displayed on your system as modified folder icons, as shown to the
left. Each Project folder contains a collection of information related to testing.
The information is organized into predefined subfolders, as shown in the
expanded Sample Project below.
Project folders contain various
files centered around test
design and test execution.
Projects also contain settings
that include references to
common support file stored
elsewhere (as shown to the
right). Project folders are
displayed with a double-red line
notation.
Project 1
Station
Config files
Calibration
files
MPT Test
Procedure file
templates
Project 2
Project 3
Files referenced in Projects
scf
Project folder icon
Project folders contain
predefined subfolders.
