MTS Series 793 Controller Overview
About MTS FlexTest Models 40/60/100/200
Controller Hardware 20
Types of MTS Series
793 Controllers
MTS offers several types of Series 793 Controllers. This manual pertains to the
following:
• MTS FlexTest Series 40/60/100/200 Controllers
• FlexTest GT Controllers
• FlexTest SE Controllers (Basic, Plus, and 2-Channel models)
• FlexTest IIm Controllers
Note For information about the hardware included in FlexTest GT, FlexTest
SE, and FlexTest IIm Controllers, see the MTS Series 793 Controller
Hardware manual (PN 100-147-133). For more information on Series
494 controllers, see the Series 494 Controller Hardware manual (PN
100-187-204).
About MTS FlexTest Models 40/60/100/200 Controllers
MTS FlexTest Models 40/60/100/200 Controllers are generally used in
servohydraulic test systems. They provide real-time closed-loop control, with
transducer conditioning and function generation to drive various types of servo-
actuators.
A FlexTest Controller consists of:
• One or more Series 494 Hardware chassis that contain controller hardware.
• A computer workstation that runs MTS controller applications.
Controller capabilities
P ARAMETER F LEX T EST
40
F LEX T EST
60
F LEX T EST
100
F LEX T EST
200
Test Stations 2 Up to 6* Up to 8 Up to 8
Control Channels Up to 4 Up to 8 Up to 16 Up to 40
Conditioned
Transducer Inputs Up to 12 Up to 24 Up to 40 Up to 80
Auxiliary Data Inputs Up to 16 Up to 32 Up to 64 Up to 96
*With On/Off Hydraulic Service Manifolds only
