MTS Series 793 Controller User Manual
Page 33
Controller Hardware Options
MTS Series 793 Controller Overview
Controller Hardware
33
Thumbwheel. Manually
positions the actuator when
Manual Command is enabled
Programmable Display.
Shows sensor output and
the current control mode.
You can use it to zero
sensors and change
control modes.
Interlock Indicators
Hydraulics Off
Model 494.05 Handset
*MC SN1 Ch1
>Displ 130.5
-Force 200 kN
Hydraulics Indicator
Exclusive Control
Interlock Reset/Override
Program Run/Stop/
Hold Controls
Manual Command
