13435743_EDBM301_v14 .0 41
PARAMETER MENU
PARAM .
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
28 AUTO/MAN
A / M LOC
AUTO
MANUAL
A / M SPD
A / M LOC
30 CONTROL
LOCAL
REMOTE
SERIAL
kEYPAD
TB STRIP
kEYPAD 2
LOCAL
31 UNITS
sp: HERTZ, RPM, % HZ,
speed: HERTZ
/SEC, /MIN, /HR, GPH, NONE
pid: %, PSI, FPM, CFM, GPM, IN,
FT, /SEC, /MIN, /HR, F, C, MPM,
GPH
32 HZ MULT 0 .10 - 650 .0 1 .00
33 UNITS DP
XXXXX
XXX .X
XX .XX
X .XXX
.XXXX
XXXXX
34 LOAD MLT 95 - 139 % 100%
35 CONTRAST
LOW
MED
HIGH
MED
36 SLEEP TH 0 .00 - 360 .0 Hz 0 .00 Hz
37 SLEEP DL 0 .0 - 300 SEC 30 .0 SEC
38 SLEEP BW FB @ MIN - FB @ MAX 0%
39 TB5 MIN 0 .00 - 360 .0 Hz 0 .00 Hz
40 TB5 MAX 0 .00 - 360 .0 Hz 60 .00 Hz
41 AIN FLTR 0 .01 - 10 .0 SEC 0 .02 SEC
42 TB10A OUT
NONE
0-10V
2-10V
NONE
43 @TB10A 0 .00 - 360 .0 Hz 60 .00 Hz
44 TB10B OUT
NONE
0-10V
2-10V
NONE
45 @TB10B 10 - 200 % 125 %
47 TB13A
NONE, 0-10VDC, 4-20MA,
NONE SPEED#1, LOC SEL,
DEC FREQ
