RUN > 460 VAC
DRIVE
STATUS
MOTOR
VOLTAGE
DIRECTION
(FORWARD)
NOTE
During acceleration and deceleration to the SPEED SETPOINT, the
DRIVE STATUS will show the actual drive speed . When the SPEED
SETPOINT is reached, the DRIVE STATUS will change to RUN (or
STOP if the drive is decelerating to a STOP) .
13 .2 .3 MC3000 DISPLAY IN FAULT MODE
When the drive trips on a fault, the display will automatically change to the FAULT display,
which indicates the FAULT MESSAGE:
FAULT: OVERLOAD
DRIVE
STATUS
FAULT
MESSAGE
In FAULT mode, the ENTER key will toggle the display between four screens: FAULT,
SPEED, % LOAD and VAC . The DRIVE STATUS for these displays will be FAULT . An
example is shown below of the drive in the FAULT mode displaying SPEED .
FAULT > 60.00 HZ
DRIVE
STATUS
SPEED
SETPOINT
SPEED
UNITS
DIRECTION
(FORWARD)
NOTE
To clear a FAULT, press the STOP key, issue a remote STOP
command at TB-1, or use TB-13D (refer to Parameter 50 - TB13D) .
