26 13435743_EDBM301_v14 .0
The following table shows the possible DRIVE STATUS indications that can appear on
the drive display:
DRIVE STATUS TABLE
DISPLAY DESCRIPTION
STOP Drive to STOP mode - No output to motor .
RUN Drive is in RUN mode and is within + 0 .3 Hz of the speed setpoint .
FAULT
Drive has shut down due to a FAULT condition . If the fault condition
has passed, pressing the STOP key will clear the fault and return the
drive to the STOP mode .
LOCk Drive is in FAULT LOCkOUT after five unsuccessful restart attempts .
BRAkE DC BRAkE is energized .
LIMIT
Drive is in CURRENT LIMIT due to an overloaded motor, or ACCEL
is set too fast .
F DEC Drive is in DECEL FREEZE because DECEL is set too fast .
13 .2 .2 MC3000 DISPLAY IN RUN MODE
When the drive is in the RUN mode, the default display will look like this:
RUN > 60.00 HZ
DRIVE
STATUS
SPEED
SETPOINT
SPEED
UNITS
DIRECTION
(FORWARD)
As in the STOP mode, the ENTER key can be used to toggle the display from SPEED
to % LOAD to VAC (motor voltage):
RUN > 85% LOAD
DRIVE
STATUS
PERCENT
LOAD
DIRECTION
(FORWARD)
