Lenze MC3000 Series - Manual (Page 44)

40 13435743_EDBM301_v14 .0
17 PARAMETER MENU
PARAMETER MENU
PARAM .
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
0 LINE VOLTS
HIGH
LOW
AUTO
AUTO
1 SPEED #1 MIN FRQ - MAX FRQ 20 .00 Hz
2 SPEED #2 MIN FRQ - MAX FRQ 20 .00 Hz
3 SPEED #3 MIN FRQ - MAX FRQ 20 .00 Hz
4 SPEED #4 MIN FRQ - MAX FRQ 20 .00 Hz
5 SkIP #1 0 .00 Hz - MAX FRQ 0 .00 Hz
6 SkIP #2 0 .00 Hz - MAX FRQ 0 .00 Hz
7 BAND WID 0 .00 - 10 .00 Hz 1 .00 Hz
8 ACCEL (NOTE 1) 30 .0 SEC
9 DECEL (NOTE 1) 30 .0 SEC
10 MIN FRQ 0 .00 - MAX FRQ .50 Hz
11 MAX FRQ MIN FRQ - 120 .0 Hz 60 .00 Hz
12 DC BRAkE (NOTE 1) 0 .0 VDC
13 DC TIME 0 .0 - 999 .9 SEC 0 .0 SEC
14 DYN BRAkE
OFF
ON
OFF
16 CURRENT 25 - 180 % (NOTE 2) 180%
17 MOTOR OL 25 - 100 % 100%
18 BASE 20 .00 - 360 .0 Hz 60 .00 Hz
19 FX BOOST 0 .0 - 30 .0 % (NOTE 1)
22 TORQUE
CONSTANT
VARIABLE
CT / NOCMP
CONSTANT
23 CARRIER 2 .5, 6, 8, 10, 12, 14 kHz 2 .5 kHz
25 START
NORMAL
POWER UP
AUTO 1
AUTO 2
AUTO 3
NORMAL
26 STOP
COAST
RAMP
RAMP2
COAST
NOTE 1: Refer to SECTION 18 - DESCRIPTION OF PARAMETERS
NOTE 2: If line volts is set to "LOW" (or set to "AUTO" and the input voltage is
low), the range is 25 - 150% .
